Key Features
- Cattle EID reading– supports compatible EMID and FDX-B animal identification tags.
- Compact handheld design– suitable for close-range cattle ear tag checks without carrying a full-length stick reader.
- Clear TFT display– shows the scanned identification number and reader status directly on the device.
- Onboard record storage– IDs can be collected in the field before transferring them to another system.
- Flexible data transfer– supports USB 2.0 and 2.4G wireless, with Bluetooth available as an option.
- Fast tag detection– designed for quick individual animal identification during routine scanning.
- Visual and audible confirmation– the display and built-in buzzer help confirm successful tag reads.
Technical Specifications
| Feature | Specification |
| Model | JIA-91D |
| Product Type | Handheld Cattle Ear Tag Scanner |
| Operating Frequency | 125 kHz / 134.2 kHz |
| Supported Formats | EMID, FDX-B |
| Animal ID Standard | ISO 11784 / ISO 11785 |
| Glass Transponder Read Distance | >8 cm with compatible 2–12 mm transponder |
| Animal Ear Tag Read Distance | >20 cm with compatible 30 mm ear tag |
| Read Time | <100 ms |
| Display | 1.44-inch TFT LCD |
| Scan Indication | TFT display and buzzer |
| Storage Capacity | Up to 1,000 records |
| Communication Interfaces | USB 2.0, 2.4G wireless, optional Bluetooth |
| 2.4G Wireless Distance | Up to 80 m in open, unobstructed conditions |
| Bluetooth Distance | Up to 20 m in open, unobstructed conditions |
| Battery | 3.7V, 800mAh rechargeable lithium battery |
| Dimensions | 182 × 77 × 17.5 mm |
| Net Weight | 78 g |
| Operating Temperature | -10°C to +50°C |
| Storage Temperature | -30°C to +70°C |
| Operating Humidity | 5%–95% non-condensing |
| Language | English; customization available |
Reading note: Actual reading distance depends on tag size, tag performance, orientation, reader position, and the surrounding environment.
Wireless note: Communication distance may be reduced by walls, equipment, interference, or other obstacles.
Cattle Identification Applications
The JIA-91D is designed for situations where cattle need to be identified individually by their electronic ear tag.
Typical uses include cattle registration, routine herd checks, breeding records, animal movement verification, and collecting tag IDs before transferring them to farm or livestock management software.
Its compact format is particularly useful when animals can be approached or restrained closely enough for short-range handheld scanning.
For operations that require scanning from farther away while cattle are moving through races or chutes, a longer stick reader or fixed reader may be more suitable.
The reader retrieves the electronic identification number stored in the tag. Animal history, ownership, weight, health, or breeding information is normally managed in a separate database or livestock management system.
Cattle Ear Tag Scanner FAQs
Does the JIA-91D support HDX cattle ear tags?
No. The confirmed supported formats for the JIA-91D are EMID and FDX-B.
If your cattle tags use HDX, another reader model with confirmed HDX support should be selected.
Can the scanner be used without a computer or phone connected?
Yes. Scanned tag IDs can be stored in the reader’s internal memory and transferred later.
This is useful when scanning cattle in areas where a computer, phone, or network connection is not immediately available.
What can affect cattle ear tag reading performance?
Tag size, antenna design, orientation, distance from the reader, surrounding metal, electrical interference, and the way the animal is positioned can all affect scanning performance.
For more consistent results, bring the reader toward the ear tag with a clear scanning path rather than relying on a single fixed angle.
